E-Plan macros for UGVNG 20 and ESB 10.2

Our DC innovation UGVNG 20 and the new electronic current limiter ESB 10.2 are now also available as E-Plan macros.

You can use the product macros to embed the devices directly into your application. Symbol macros are available, which can be used for creating circuit diagrams, for example, as well as 2D and 3D macros for a specific layout.

You can download the E-plan data for the UGVNG and ESB, as well as all our switching power supply units and DC UPS systems, here:
https://www.woehrle-svs.de/download/eplan-makros

You can find more information about the new products here:

To the UGVNG 20 product page

To the ESB 10.2 product page
